Mecair 400/500 Series – Full Immersion Pulse Valves

Category: Brands:


Technical Documents (pdf):
Mecair-400 Series FullImmersion
Mecair-400 Series FullImmersion – Spares
Manifold Mount 400 Pulse Jet Valves

  • Suitable for low-pressure (0.5 – 1.5 bar), and high-pressure systems (0.5 – 7.5 bar)
  • Designed for dust collectors, in particular for reverse pulse jet filter cleaning of filter bags, cartridges and envelope, ceramic and sintered metal fibre filters.
  • Designed to be installed on flat surfaces or square/rectangular tanks.
  • Named “full immersion” as the valve draws the compressed air directly from the header tank, leading to improved pneumatic performance.
  • Can be supplied complete with the blow tube and counter flange.
  • Fixed to the tank with a special counter flange and fixing screws.
  • The 2″, 21/2″ and 3″ valves are all double diaphragm valves; the 11/2″ model can be a single or double diaphragm valve.
  • Made of diecast aluminium with an anodised treatment which protects against corrosive and environmental agents.
  • Bolts and screws are stainless steel.
  • Available with integrated solenoid pilot (VNP) or with remote pneumatic connection (VEM).

More info: https://goyenmecair.pentair.com/en
